產品名稱: |
Current Limiting Diodes |
製造商: |
Diotec |
產品特色: |
1. Constant current source, current regulators |
|
|
2. Applications: Low power LED drivers and battery chargers, constant current regulators for simple sensor circuits, Power supply for µController |
|
|
3. Compliant to RoHS, REACH, Conflict Minerals |
|
|
4. Suffix -AQ: in AEC-Q101 qualification |
Contact
Product List
點我查看產品列表
*捲動以查看完整資訊
| 型號 |
Type |
Package |
Peak Operating Voltage |
Regulator Current |
Junction Temperature |
Limiting Voltage |
Junction Capacitance |
|||
|
VAK[V] |
IPnom[mA] |
Tjmax[°C] |
VL[V] |
Cj[pF] |
VR[V] |
|||||
 |
 |
CL10MD | SMD | DO-213AA/MiniMelf | 90 | 20 | 150 | 3 | 5 | 0 |
|
|
CL15MD | SMD | DO-213AA/MiniMelf | 90 | 25 | 150 | 3 | 5 | 0 |
|
|
CL20MD | SMD | DO-213AA/MiniMelf | 90 | 30 | 150 | 3 | 5 | 0 |
|
|
CL30MD | SMD | DO-213AA/MiniMelf | 90 | 40 | 150 | 3 | 5 | 0 |
 |
|
CL05M6F | SMD | SOD-123FL | 190 | 6 | 150 | 5 | 0 | |
 |
|
CL15M35 | SMD | DO-214AC/SMA | 90 | 15 | 150 | 3 | ||
 |
|
CL15M45 | SMD | DO-214AA/SMB | 90 | 15 | 150 | 3 | ||
|
|
CL20M35 | SMD | DO-214AC/SMA | 90 | 20 | 150 | 3 | ||
|
|
CL20M45 | SMD | DO-214AA/SMB | 90 | 20 | 150 | 3 | ||
|
|
CL40M35 | SMD | DO-214AC/SMA | 90 | 40 | 150 | 3 | ||
|
|
CL40M45 | SMD | DO-214AA/SMB | 90 | 40 | 150 | 3 | ||
|
|
CL20M35R7 | SMD | DO-214AC/SMA | 90 | 20 | 150 | 3 | ||
|
|
CL15M35-AQ | SMD | DO-214AC/SMA | 90 | 15 | 150 | 3 | ||
|
|
CL15M45-AQ | SMD | DO-214AA/SMB | 90 | 15 | 150 | 3 | ||
|
|
CL20M35-AQ | SMD | DO-214AC/SMA | 90 | 20 | 150 | 3 | 5 | |
|
|
CL20M45-AQ | SMD | DO-214AA/SMB | 90 | 20 | 150 | 3 | 5 | |
|
|
CL40M35-AQ | SMD | DO-214AC/SMA | 90 | 40 | 150 | 3 | ||
|
|
CL40M45-AQ | SMD | DO-214AA/SMB | 90 | 40 | 150 | 3 | ||
*更多詳情請參考規格書
瑞澤電子是Diotec代理商，提供各式二極體產品，另設有現貨商城，如您需其他規格、產品型號或有相關半導體元件需求，歡迎與我們諮詢。
