| Product: | Potentiometer |
| Manufacturer: | Forward |
| Features: | 1. Outset molding with resin around the resistor prevents flux build-up. |
| 2. Red、green、blue and orange LED colors are available. |
Contact
| Specifications | |
| Packaging method: | Bag |
| Installation type: | DIP |
| Operating temp: | Please refer to the product spec |
| Ampacity: | 10mA(Switch rating) |
| Rated voltage: | D.C.5V(Switch rating) Max operating voltage:50V AC 10V DC |
| Size (mm) (L*W*H): |
13.2X13.2X22.4 |
| note | For further information, please contact:+886-3-4266335 |
