| Product: | Wire to Board Connector |
| Manufacturer: | CJT Conn |
| Features: | 1. Includes wire-to-board and wire-to-wire connection methods. |
| 2. Maximum operating voltage can reach 250V, with each contact rated for 5A. | |
| 3. Supports various latch structures and requires minimal installation space. | |
| 4. DIP, SMT, PIP/PIH | |
| 5. UL/cUL certified. | |
| 6. Applications: communication equipment, automotive, home appliances, medical, and new energy. |
Contact
| Spec | |
| Pitch | 2.54mm(.100in) |
| Current rating | 3A AC,DC |
| Voltage rating | 250V AC,DC |
| Temperature range | -40℃ ~ +105℃ |
| Contact resistance |
20mΩ Max. |
| Insulation resistance | 1000MΩMin. |
| Withstanding voltage |
1500V AC/minute |
*Compliant with RoHS and REACH*
*Meet the HF/Halogen Free,need to customize*
Wire-to-board connectors are connectors used to connect wires or cables to circuit boards, enabling current or signals to be transmitted from the wire to the circuit board.
Connector manufacturer CJT Conn offers the A2547 series 2.54mm pitch wire-to-board connector products to meet your reliable connection needs.
Horustech Electronics is an officially authorized distributor of CJT Conn and various connector manufacturers, providing a variety of wire-to-board connector products. With thousands of corresponding specifications, we offer pin-to-pin replacements for various connectors. If you have related connector procurement needs, please contact us. (Click the button below to find connector stock)
