Product: |
Digital Transistors |
Manufacturer: |
Diotec |
Features: |
1. Digital controls, signal processing |
|
|
2. Cost and space savings by integrated bias resistor combinations |
|
|
3. Compliant to RoHS, REACH, Conflict Minerals |
|
|
4. Suffix -Q: AEC-Q101 compliant Suffix -AQ: in AEC-Q101 qualification |
Contact
Product List
Diotec Digital Transistors Product List
*Zoom in/out the webpage to view complete information.
| Part No. |
Type |
Package |
Collector Emitter Voltage |
DC Collector Current |
Junction Temperature |
Polarity |
Power Dissipation |
Resistor |
|||
|
VCEO[V] |
IC[mA] |
Tjmax[°C] |
pol[] |
Ptot[W] |
R1[Ω] |
R2[Ω] |
|||||
 |
 |
BCR08PN | SMD | SOT-363 | 50 | 100 | 150 | NPN+PNP | 0.250 | 2200 | 47000 |
|
|
BCR22PN | SMD | SOT-363 | 60 | 100 | 150 | NPN+PNP | 0.200 | 22000 | 22000 |
 |
 |
MMDTD141 | SMD | SOT-23 | 50 | 500 | 150 | NPN | 0.200 | 10000 | 10000 |
 |
 |
MMDT5111W | SMD | SOT-323 | 50 | 100 | 150 | PNP | 0.200 | 10000 | 10000 |
|
|
MMDT5112W | SMD | SOT-323 | 50 | 100 | 150 | PNP | 0.200 | 22000 | 22000 |
|
|
MMDT5114W | SMD | SOT-323 | 50 | 100 | 150 | PNP | 0.200 | 10000 | 47000 |
|
|
MMDT5211W | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 10000 |
|
|
MMDT5212W | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 22000 | 22000 |
|
|
MMDT5213W | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 47000 | 47000 |
|
|
MMDT5214W | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 47000 |
|
|
BCR08PN-AQ | SMD | SOT-363 | 50 | 100 | 150 | NPN+PNP | 0.250 | 2200 | 47000 |
|
|
BCR22PN-AQ | SMD | SOT-363 | 60 | 100 | 150 | NPN+PNP | 0.200 | 22000 | 22000 |
|
|
MMBTRA226S | SMD | SOT-23 | 50 | 800 | 150 | PNP | 0.200 | 2200 | 10000 |
|
|
MMDTA141DW | SMD | SOT-363 | -50 | -100 | 150 | PNP | 0.200 | 10000 | 10000 |
|
|
MMBTRA101SS | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 4700 | 4700 |
|
|
MMBTRA102SS | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 10000 | 10000 |
|
|
MMBTRA103SS | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 22000 | 22000 |
|
|
MMBTRA104SS | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 47000 | 47000 |
|
|
MMBTRA105SS | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 2200 | 47000 |
|
|
MMBTRA106SS | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 4700 | 47000 |
|
|
MMBTRC101SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 4700 |
|
|
MMBTRC102SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 10000 |
|
|
MMBTRC103SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 22000 | 22000 |
|
|
MMBTRC104SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 47000 | 47000 |
|
|
MMBTRC105SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 2200 | 47000 |
|
|
MMBTRC106SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 47000 |
|
 |
MMBTRC110SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | |
|
|
MMBTRC113SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 22000 | |
|
|
MMBTRC116SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 1000 | 10000 |
|
|
MMBTRC117SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 2200 | 2200 |
|
|
MMBTRC118SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 2200 | 10000 |
|
|
MMBTRC119SS | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 10000 |
|
|
MMDT5111W-Q | SMD | SOT-323 | 50 | 100 | 150 | PNP | 0.200 | 10000 | 10000 |
|
|
MMDT5211W-Q | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 10000 |
|
|
MMDT5214W-Q | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 47000 |
|
|
MMDT5213W-AQ | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 47000 | 47000 |
|
|
MMDT521LW-AQ | SMD | SOT-323 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 4700 |
|
|
MMDTA141DW-Q | SMD | SOT-363 | 60 | 100 | 150 | PNP | 0.200 | 10000 | 10000 |
|
|
MMBTRA106SS-Q | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 4700 | 47000 |
|
|
MMBTRC102SS-Q | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 10000 |
|
|
MMBTRC105SS-Q | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 2200 | 47000 |
|
|
MMBTRC106SS-Q | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 47000 |
|
|
MMBTRC110SS-Q | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | |
 |
|
MMDTC124EE-AQ | SMD | SOT-523 | 50 | 30 | 150 | NPN | 0.150 | 22000 | 22000 |
|
|
MMBTRA106SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | PNP | 0.200 | 4700 | 47000 |
|
|
MMBTRC101SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 4700 |
|
|
MMBTRC102SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 10000 | 10000 |
|
|
MMBTRC103SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 22000 | 22000 |
|
|
MMBTRC104SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 47000 | 47000 |
|
|
MMBTRC106SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 4700 | 47000 |
|
|
MMBTRC118SS-AQ | SMD | SOT-23 | 50 | 100 | 150 | NPN | 0.200 | 2200 | 10000 |
Horustech is a Diotec distributor that provides various semiconductor components. If you have any related needs, please feel free to contact us online.
