Product: |
Arrays |
Manufacturer: |
Diotec |
Features: |
1. Combination of diodes (phase-out product) |
|
|
2. Compliant to RoHS, REACH, Conflict Minerals |
Contact
Product List
Diotec Arrays Product List
*Zoom in/out the webpage to view complete information.
| Part No. |
Type |
Package |
Maximum Average Forward Rectified Current |
Junction Temperature |
Reverse Recovery Time |
Peak Forward Surge Current |
Forward Voltage |
Leakage Current |
||
|
IFAV[A] |
Tjmax[°C] |
trr[ns] |
IFSM[A] |
VF[V] |
IF[A] |
IR[µA] |
VR[V] |
|||
| DAN601 | Array | 7 Pin 18x3.5x6.6 | 0.10 | 150 | 4 | 0.50 | 1.00 | 0.01 | 0.025 | 20 |
| DAP208 | Array | 3 Pin 8.5x3.5x6.6 | 1.00 | 150 | 10.00 | 1.20 | 1.00 | 0.010 | 100 | |
| DAP801 | Array | 9 Pin 24x3.5x6.6 | 0.10 | 150 | 4 | 0.50 | 1.00 | 0.01 | 0.025 | 20 |
*Please refer to the specification sheet for more details.
Horustech is a Diotec distributor that provides various semiconductor components. If you have any related needs, please feel free to contact us online.
