Product: |
SiC Schottky Diodes |
Manufacturer: |
Diotec |
Features: |
1. Output rectification |
|
|
2. Polarity protection |
|
|
3. Compliant to RoHS, REACH, Conflict Minerals |
Contact
Product List
*Zoom in/out the webpage to view complete information.
| Part No. | Type | Package | Repetitive Peak Reverse Voltage | Maximum Average Forward Rectified Current | Junction Temperature | Forward Voltage | Peak Forward Surge Current |
Leakage Current |
Junction Capacitance |
|||||
| VRRM[V] |
IFAV[A] |
Tjmax[°C] |
VF[V] | IF[A] |
IFSM[A] |
IR[µA] |
VR[V] |
Cj[pF] |
VR[V] |
|||||
 |
 |
SI20C120D2 | SMD | TO-263AB/D2PAK | 1200 | 20.00 | 175 | 1.80 | 20.00 | 150.00 | 20.000 | 1200 | 80 | 800 |
 |
 |
SICW20C120 | Wire-lead | TO-247-3L | 1200 | 20.00 | 175 | 1.80 | 10.00 | 95.00 | 100.000 | 1200 | 41 | 800 |
|
|
SICW40C120 | Wire-lead | TO-247-3L | 1200 | 40.00 | 175 | 1.80 | 20.00 | 180.00 | 100.000 | 1200 | 80 | 800 |
*Please refer to the specification sheet for more details.
Horustech is a Diotec distributor that provides various semiconductor components. If you have any related needs, please feel free to contact us online.
