| Product: | POGO PIN |
| Manufacturer: | C.C.P. Contact Probes Co., LTD. |
| Features: | 1. Easy to plug-in, no accidental rip-off of the cable |
| 2. Stable current flow | |
| 3. Miniaturized & high current | |
| 4. High durability |
Contact
| Specifications | |
| Packaging method: | Tape&Reel |
| Installation type: | SMD |
| Operating temp: | -20℃ ~ +60℃ |
| Ampacity: | 2A |
| Rated voltage: | DC 12V |
| Length(mm): | 5.9 |
| Working Height (mm): | 4.7 |
| Spring Force: | 110g±20g |
| note | For further information, please contact:+886-3-4266335 |
