Product: | POGO PIN |
Manufacturer: | C.C.P. Contact Probes Co., LTD. |
Features: | 1. Easy to plug-in, no accidental rip-off of the cable |
2. Stable current flow | |
3. Miniaturized & high current | |
4. High durability |
Contact
Specifications | |
Packaging method: | Tape&Reel |
Installation type: | SMD |
Operating temp: | -20℃ ~ +60℃ |
Ampacity: | 1A |
Rated voltage: | DC 12V |
Length(mm): | 4.2 |
Working Height (mm): | 3.1 |
Spring Force: | 80g±20% |
note | For further information, please contact:+886-3-4266335 |
