Product: |
MOSFETs (Field Effect Transistors) |
Manufacturer: |
Diotec |
Features: |
1. (Power) switches and signal processing |
|
|
2. Tiny, space saving package |
|
|
3. Low on state resistance |
|
|
4. Fast switching times |
|
|
5. Compliant to RoHS, REACH, Conflict Minerals |
|
|
6. Suffix -Q: AEC-Q101 compliant Suffix -AQ: in AEC-Q101 qualification |
Contact
Product List
Diotec MOSFET Product List
*Zoom in/out the webpage to view complete information.
| Part No. |
Type |
Package |
Drain Source Voltage |
Drain Current |
Junction Temperature |
Polarity |
Power Dissipation |
Peak Drain Current |
Threshold Voltage |
On-Resistance |
Turn-On Time |
Turn-Off Time |
||||
|
VDS[V] |
ID[A] |
Tjmax[°C] |
pol[] |
Ptot[W] |
IDM[A] |
VGSth[V] |
RDSon[Ω] |
ID[A] |
VGS[V] |
ton[ns] |
toff[ns] |
|||||
 |
 |
2N7000 | Wire-lead | TO-92 | 60 | 0.200 | 150 | N | 0.350 | 0.500 | 0.8 | 5.0000 | 1 | 10 | 10 | 10 |
 |
|
2N7002 | SMD | SOT-23 | 60 | 0.280 | 150 | N | 0.350 | 1.200 | 2.5 | 5.0000 | 1 | 10 | 20 | 20 |
|
|
2N7002A | SMD | SOT-23 | 60 | 0.280 | 150 | N | 0.350 | 1.200 | 2.5 | 2.0000 | 1 | 10 | 20 | 20 |
 |
|
2N7002W | SMD | SOT-323 | 60 | 0.115 | 150 | N | 0.200 | 0.800 | 2.5 | 13.5000 | 1 | 10 | ||
|
|
MMFTN20 | SMD | SOT-23 | 50 | 0.100 | 150 | N | 0.300 | 0.300 | 0.4 | 15.0000 | 0 | 10 | 5 | 10 |
|
 |
MMFTP84 | SMD | SOT-23 | -60 | -0.130 | 150 | P | 0.250 | -0.520 | -0.8 | 10.0000 | 0 | -10 | 3 | 7 |
|
|
2N7002PW | SMD | SOT-323 | 60 | 0.315 | 150 | N | 0.310 | 1.200 | 2.5 | 1.6000 | 1 | 10 | 7 | 15 |
 |
|
MD06P115 | SMD | SOT-26 | -60 | -3.100 | 150 | P | 1.500 | -20.000 | -2.5 | 0.0850 | -4 | -10 | 20 | 17 |
|
|
MD10P380 | SMD | SOT-26 | -100 | -1.600 | 150 | P | 1.000 | -9.000 | -2.3 | 0.3250 | -1 | -10 | 12 | 16 |
|
|
MMFTN123 | SMD | SOT-23 | 100 | 0.170 | 150 | N | 0.360 | 0.680 | 0.8 | 6.0000 | 0 | 10 | 21 | 36 |
|
|
MMFTN138 | SMD | SOT-23 | 50 | 0.220 | 150 | N | 0.360 | 0.880 | 0.8 | 3.5000 | 0 | 10 | 20 | 38 |
|
|
MMFTN170 | SMD | SOT-23 | 60 | 0.500 | 150 | N | 0.300 | 0.800 | 0.8 | 5.0000 | 0 | 10 | 10 | 10 |
|
|
MMFTP84W | SMD | SOT-323 | -50 | -0.130 | 150 | P | 0.250 | -0.520 | -1.6 | 10.0000 | 0 | -10 | 3 | 7 |
|
 |
2N7002KPW | SMD | SOT-323 | 60 | 0.310 | 150 | N | 0.275 | 1.200 | 2.1 | 1.6000 | 1 | 10 | 8 | 20 |
|
|
2N7002W-Q | SMD | SOT-323 | 60 | 0.115 | 150 | N | 0.200 | 0.800 | 2.5 | 13.5000 | 1 | 10 | ||
 |
 |
DID3A2N65 | SMD | TO-251/I-PAK | 650 | 3.200 | 150 | N | 54.000 | 16.000 | 4.0 | 2.6000 | 2 | 10 | 145 | 330 |
 |
|
DIJ2A3N65 | Wire-lead | ITO-220AB | 650 | 2.300 | 150 | N | 30.000 | 16.000 | 4.0 | 2.6000 | 2 | 10 | 23 | 58 |
|
|
DIJ4A5N65 | Wire-lead | ITO-220AB | 650 | 4.500 | 150 | N | 46.000 | 28.000 | 4.0 | 1.3000 | 4 | 10 | 32 | 107 |
 |
|
DIT050N06 | Wire-lead | TO-220AB | 60 | 50.000 | 175 | N | 85.000 | 90.000 | 1.9 | 0.0140 | 20 | 10 | 12 | 34 |
|
|
DIT085N10 | Wire-lead | TO-220AB | 100 | 85.000 | 150 | N | 62.500 | 480.000 | 2.4 | 0.0048 | 50 | 10 | 69 | 31 |
|
|
DIT090N06 | Wire-lead | TO-220AB | 65 | 90.000 | 175 | N | 160.000 | 310.000 | 2.9 | 0.0057 | 30 | 10 | 26 | 65 |
|
|
DIT095N08 | Wire-lead | TO-220AB | 80 | 95.000 | 175 | N | 170.000 | 320.000 | 2.9 | 0.0066 | 40 | 10 | 30 | 71 |
|
|
DIT100N10 | Wire-lead | TO-220AB | 100 | 100.000 | 175 | N | 200.000 | 380.000 | 3.0 | 0.0099 | 40 | 10 | 65 | 95 |
|
|
DIT120N08 | Wire-lead | TO-220AB | 80 | 120.000 | 175 | N | 220.000 | 450.000 | 3.0 | 0.0049 | 40 | 10 | 50 | 130 |
|
|
DIT150N03 | Wire-lead | TO-220AB | 30 | 150.000 | 175 | N | 130.000 | 600.000 | 1.7 | 0.0023 | 20 | 10 | 50 | 130 |
|
|
DIT195N08 | Wire-lead | TO-220AB | 85 | 195.000 | 175 | N | 300.000 | 850.000 | 4.0 | 0.0035 | 20 | 10 | 128 | 127 |
 |
|
DIW085N06 | Wire-lead | TO-247-3L | 65 | 85.000 | 150 | N | 240.000 | 340.000 | 4.0 | 0.0091 | 40 | 10 | 83 | 95 |
|
|
MMBT7002K | SMD | SOT-23 | 60 | 0.300 | 150 | N | 0.350 | 0.800 | 1.0 | 3.0000 | 1 | 10 | 20 | 20 |
|
|
MMFTN138K | SMD | SOT-23 | 60 | 0.360 | 150 | N | 0.420 | 1.200 | 1.6 | 1.6000 | 0 | 10 | 27 | 12 |
|
|
MMFTN138W | SMD | SOT-323 | 50 | 0.220 | 150 | N | 0.200 | 0.880 | 1.6 | 3.5000 | 0 | 10 | 20 | 45 |
|
|
MMFTN20-Q | SMD | SOT-23 | 50 | 0.100 | 150 | N | 0.300 | 0.300 | 0.4 | 15.0000 | 0 | 10 | 5 | 10 |
|
|
MMFTN210A | SMD | SOT-23 | 100 | 2.000 | 150 | N | 1.560 | 7.200 | 1.6 | 0.3200 | 1 | 10 | 8 | 19 |
|
|
MMFTN2362 | SMD | SOT-23 | 60 | 3.000 | 150 | N | 1.250 | 12.000 | 2.5 | 0.0800 | 3 | 10 | 9 | 11 |
|
|
MMFTN3402 | SMD | SOT-23 | 30 | 4.000 | 150 | N | 1.000 | 15.000 | 1.0 | 0.0550 | 4 | 10 | 5 | 24 |
|
|
MMFTN4520 | SMD | SOT-23 | 150 | 0.425 | 150 | N | 1.000 | 1.500 | 3.0 | 4.5000 | 0 | 5 | 64 | 86 |
|
|
MMFTN6001 | SMD | SOT-23 | 60 | 0.440 | 150 | N | 0.530 | 1.000 | 1.4 | 2.0000 | 1 | 10 | 13 | 35 |
|
|
MMFTP2319 | SMD | SOT-23 | -40 | -4.200 | 150 | P | 0.750 | -30.000 | 3.0 | 0.0800 | -3 | -10 | 43 | 23 |
|
|
MMFTP3401 | SMD | SOT-23 | -30 | -4.000 | 150 | P | 1.000 | -25.000 | -1.3 | 0.0650 | -4 | -10 | 9 | 45 |
|
|
MMFTP5618 | SMD | SOT-23 | -60 | -1.250 | 150 | P | 0.500 | -10.000 | -3.0 | 0.1700 | -1 | -10 | 9 | 9 |
|
|
2N7002A-AQ | SMD | SOT-23 | 60 | 0.280 | 150 | N | 0.350 | 1.200 | 2.5 | 2.0000 | 1 | 10 | 20 | 20 |
 |
 |
DI006H03SQ | SMD | SO-8 | 30 | 6.000 | 150 | N+P | 1.500 | 60.000 | 2.0 | 0.0250 | 5 | 10 | 27 | 26 |
 |
|
DI006P02PW | SMD | PowerQFN 2x2 | -20 | -6.000 | 150 | P | 2.000 | -36.000 | -1.0 | 0.0250 | -6 | -5 | 44 | 28 |
|
|
DI008N09SQ | SMD | SO-8 | 90 | 8.000 | 150 | N | 2.000 | 23.000 | 2.5 | 0.0750 | 5 | 10 | 30 | 25 |
|
|
DI010N03PW | SMD | PowerQFN 2x2 | 30 | 10.000 | 150 | N | 1.400 | 50.000 | 2.0 | 0.0120 | 10 | 10 | 16 | 16 |
 |
|
DI015N25D1 | SMD | TO-252AA/D-PAK | 250 | 15.000 | 175 | N | 140.000 | 60.000 | 3.5 | 0.2000 | 20 | 10 | 9 | 12 |
 |
 |
DI018C03PT | SMD | PowerQFN 3x3 | 30 | -18.000 | 150 | N+P | 10.800 | -80.000 | 2.5 | 0.0300 | -10 | -10 | 40 | 17 |
|
|
DI020N06D1 | SMD | TO-252AA/D-PAK | 60 | 20.000 | 175 | N | 45.000 | 60.000 | 1.6 | 0.0240 | 20 | 10 | 12 | 20 |
|
|
DI020P06PT | SMD | PowerQFN 3x3 | -60 | -20.000 | 150 | P | 29.700 | -70.000 | -2.5 | 0.0450 | -10 | -10 | 29 | 29 |
|
|
DI025N06PT | SMD | PowerQFN 3x3 | 65 | 25.000 | 150 | N | 25.000 | 80.000 | 2.5 | 0.0200 | 8 | 10 | 13 | 7 |
|
|
DI028P03PT | SMD | PowerQFN 3x3 | -30 | -28.000 | 150 | P | 40.000 | -80.000 | -1.7 | 0.0067 | -20 | -10 | 20 | 36 |
|
|
DI030N03D1 | SMD | TO-252AA/D-PAK | 30 | 30.000 | 175 | N | 40.000 | 80.000 | 1.5 | 0.0100 | 20 | 10 | 17 | 25 |
|
|
DI035N10PT | SMD | PowerQFN 3x3 | 100 | 35.000 | 150 | N | 25.000 | 130.000 | 1.7 | 0.0140 | 7 | 10 | 21 | 17 |
|
|
DI035P02PT | SMD | PowerQFN 3x3 | -20 | -35.000 | 150 | P | 52.000 | -80.000 | -1.2 | 0.0039 | -20 | -10 | 73 | 103 |
|
|
DI035P04PT | SMD | PowerQFN 3x3 | -40 | -35.000 | 150 | P | 25.000 | -120.000 | -1.7 | 0.0190 | -10 | -10 | 40 | 32 |
|
|
DI040N03PT | SMD | PowerQFN 3x3 | 30 | 40.000 | 150 | N | 25.000 | 120.000 | 1.7 | 0.0060 | 15 | 10 | 84 | 34 |
|
|
DI040P04D1 | SMD | TO-252AA/D-PAK | -40 | -40.000 | 150 | P | 52.000 | -160.000 | -2.5 | 0.0150 | -10 | -10 | 44 | 30 |
|
|
DI040P04PT | SMD | PowerQFN 3x3 | -40 | -40.000 | 150 | P | 22.700 | -160.000 | -1.7 | 0.0150 | -10 | -10 | 19 | 26 |
|
|
DI045N03PT | SMD | PowerQFN 3x3 | 30 | 45.000 | 150 | N | 16.000 | 280.000 | 1.7 | 0.0044 | 24 | 10 | 72 | 26 |
|
|
DI050N04PT | SMD | PowerQFN 3x3 | 40 | 50.000 | 150 | N | 25.000 | 220.000 | 2.5 | 0.0057 | 10 | 10 | 48 | 24 |
|
|
DI050N06D1 | SMD | TO-252AA/D-PAK | 60 | 50.000 | 150 | N | 42.000 | 160.000 | 1.8 | 0.0085 | 10 | 10 | 26 | 11 |
|
|
DI050P02PT | SMD | PowerQFN 3x3 | -20 | -50.000 | 150 | P | 35.700 | -180.000 | -1.0 | 0.0100 | -15 | -10 | 95 | 46 |
|
|
DI050P03PT | SMD | PowerQFN 3x3 | -30 | -50.000 | 150 | P | 39.000 | -200.000 | -2.5 | 0.0080 | -20 | -10 | 75 | 34 |
|
|
DI064P04D1 | SMD | TO-252AA/D-PAK | -40 | -64.000 | 150 | P | 48.300 | -350.000 | -4.0 | 0.0076 | -30 | -10 | 96 | 40 |
|
|
DI065N06PT | SMD | PowerQFN 3x3 | 65 | 65.000 | 150 | N | 39.000 | 300.000 | 2.5 | 0.0050 | 20 | 10 | 41 | 18 |
 |
|
DI068N03PQ | SMD | PowerQFN 5x6 | 30 | 68.000 | 150 | N | 25.000 | 210.000 | 1.6 | 0.0030 | 20 | 10 | 60 | 30 |
|
|
DI068P04D1 | SMD | TO-252AA/D-PAK | -40 | -68.000 | 150 | P | 54.000 | -300.000 | -2.5 | 0.0073 | -20 | -10 | 85 | 52 |
|
|
DI070P04PQ | SMD | PowerQFN 5x6 | -40 | -70.000 | 150 | P | 46.000 | -300.000 | -2.5 | 0.0065 | -20 | -10 | 37 | 43 |
|
|
DI072N06PT | SMD | PowerQFN 3x3 | 65 | 72.000 | 150 | N | 43.000 | 280.000 | 2.5 | 0.0049 | 20 | 10 | 19 | 46 |
|
|
DI080N03PQ | SMD | PowerQFN 5x6 | 30 | 80.000 | 150 | N | 35.000 | 420.000 | 2.5 | 0.0018 | 30 | 10 | 114 | 54 |
|
|
DI080N06PQ | SMD | PowerQFN 5x6 | 65 | 105.000 | 150 | N | 80.000 | 480.000 | 2.0 | 0.0030 | 40 | 10 | 31 | 138 |
|
|
DI100N04D1 | SMD | TO-252AA/D-PAK | 40 | 100.000 | 150 | N | 69.000 | 450.000 | 2.5 | 0.0040 | 30 | 10 | 103 | 46 |
|
|
DI100N10PQ | SMD | PowerQFN 5x6 | 100 | 80.000 | 150 | N | 50.000 | 480.000 | 2.4 | 0.0045 | 50 | 10 | 69 | 31 |
|
|
DI110N03PQ | SMD | PowerQFN 5x6 | 30 | 110.000 | 150 | N | 35.000 | 420.000 | 2.5 | 0.0018 | 30 | 10 | 114 | 54 |
|
|
DI110N04PQ | SMD | PowerQFN 5x6 | 40 | 110.000 | 150 | N | 45.000 | 450.000 | 1.7 | 0.0025 | 23 | 10 | 61 | 24 |
|
|
DI110N06D1 | SMD | TO-252AA/D-PAK | 65 | 110.000 | 150 | N | 71.000 | 550.000 | 2.5 | 0.0032 | 30 | 10 | 65 | 31 |
 |
|
DI110N06D2 | SMD | TO-263AB/D2PAK | 60 | 110.000 | 150 | N | 62.500 | 480.000 | 4.0 | 0.0032 | 100 | 10 | 108 | 36 |
|
|
DI110N15PQ | SMD | PowerQFN 5x6 | 150 | 110.000 | 150 | N | 62.000 | 145.000 | 2.5 | 0.0117 | 20 | 10 | 73 | 47 |
|
|
DI150N03PQ | SMD | PowerQFN 5x6 | 30 | 150.000 | 150 | N | 86.000 | 400.000 | 1.6 | 0.0018 | 30 | 10 | 33 | 135 |
|
|
DI150N04PQ | SMD | PowerQFN 5x6 | 40 | 150.000 | 150 | N | 125.000 | 400.000 | 4.0 | 0.0014 | 75 | 10 | 9 | 33 |
|
|
DI200N04D2 | SMD | TO-263AB/D2PAK | 40 | 200.000 | 150 | N | 225.000 | 800.000 | 4.0 | 0.0016 | 120 | 10 | 24 | 69 |
|
|
DI200N04PQ | SMD | PowerQFN 5x6 | 40 | 200.000 | 150 | N | 180.000 | 800.000 | 4.0 | 0.0013 | 100 | 10 | 22 | 67 |
|
|
DI200N10D2 | SMD | TO-263AB/D2PAK | 100 | 200.000 | 175 | N | 340.000 | 950.000 | 4.0 | 0.0023 | 120 | 10 | 66 | 115 |
 |
|
DI280N10TL | SMD | HSOF-8/TOLL | 100 | 280.000 | 175 | N | 425.000 | 1200.000 | 4.2 | 0.0020 | 50 | 10 | 58 | 170 |
|
|
DI7A6N10SQ | SMD | SO-8 | 100 | 7.600 | 150 | N | 2.500 | 200.000 | 4.0 | 0.0200 | 8 | 10 | 34 | 64 |
|
|
MD06P115-Q | SMD | SOT-26 | -60 | -3.100 | 150 | P | 1.500 | -20.000 | -2.5 | 0.0850 | -4 | -10 | 20 | 17 |
|
|
MD10P380-Q | SMD | SOT-26 | -100 | -1.600 | 150 | P | 1.000 | -9.000 | -2.3 | 0.3250 | -1 | -10 | 12 | 16 |
 |
 |
MMBT7002DW | SMD | SOT-363 | 60 | 0.115 | 150 | N+N | 0.200 | 0.800 | 2.5 | 7.5000 | 1 | 10 | 20 | 20 |
|
 |
MMFT8472DW | SMD | SOT-363 | 50 | 0.115 | 150 | N+P | 0.200 | 0.520 | 1.6 | 10.0000 | 0 | 10 | 20 | 20 |
|
|
MMFTN123-Q | SMD | SOT-23 | 100 | 0.170 | 150 | N | 0.360 | 0.680 | 0.8 | 6.0000 | 0 | 10 | 21 | 36 |
|
|
MMFTN138-Q | SMD | SOT-23 | 50 | 0.220 | 150 | N | 0.360 | 0.880 | 0.8 | 3.5000 | 0 | 10 | 20 | 38 |
|
|
MMFTN3018W | SMD | SOT-323 | 30 | 0.100 | 150 | N | 0.200 | 0.400 | 0.8 | 8.0000 | 0 | 4 | ||
|
|
MMFTN3404A | SMD | SOT-23 | 30 | 5.600 | 150 | N | 1.250 | 22.000 | 2.1 | 0.0230 | 6 | 10 | 40 | 14 |
|
|
MMFTN3422K | SMD | SOT-23 | 30 | 4.200 | 150 | N | 1.250 | 20.000 | 1.2 | 0.0420 | 4 | 10 | 1206 | 991 |
|
 |
MMFTN620KD | SMD | SOT-26 | 60 | 0.350 | 150 | N | 0.500 | 1.000 | 1.5 | 1.5000 | 1 | 10 | 8 | 31 |
|
 |
MMFTP3008K | SMD | SOT-23 | -30 | -0.360 | 150 | P | 0.500 | -1.400 | -1.0 | 2.5000 | 0 | -5 | 16 | 60 |
|
|
MMFTP3334K | SMD | SOT-23 | -30 | -4.000 | 150 | P | 1.000 | -16.000 | -1.4 | 0.0710 | -3 | -10 | 13 | 22 |
|
 |
MMFTP6312D | SMD | SOT-26 | -20 | -2.300 | 150 | P | 0.960 | 7.000 | -1.5 | 0.1150 | -2 | -5 | 21 | 26 |
|
|
2N7002KPW-Q | SMD | SOT-323 | 60 | 0.310 | 150 | N | 0.275 | 1.200 | 2.1 | 1.6000 | 1 | 10 | 8 | 20 |
|
|
DI001N65PTK | SMD | PowerQFN 3x3 | 650 | 1.000 | 150 | N | 32.200 | 4.000 | 2.5 | 1.6000 | 1 | 10 | 20 | 105 |
|
 |
DI003N03SQ2 | SMD | SO-8 | 30 | 3.000 | 150 | N | 1.600 | 9.000 | 2.5 | 0.0500 | 1 | 10 | 39 | 20 |
|
|
DI005N06SQ2 | SMD | SO-8 | 60 | 5.000 | 150 | N | 1.700 | 30.000 | 3.0 | 0.0400 | 5 | 10 | 16 | 25 |
 |
|
DI038N04PQ2 | SMD | PowerQFN 5x6-Dual | 45 | 38.000 | 150 | N+N | 31.000 | 160.000 | 1.6 | 0.0100 | 10 | 10 | 47 | 19 |
|
|
DI048N04PQ2 | SMD | PowerQFN 5x6-Dual | 40 | 48.000 | 150 | N+N | 28.000 | 200.000 | 1.8 | 0.0080 | 12 | 10 | 47 | 19 |
|
|
DI049N06PTK | SMD | PowerQFN 3x3 | 65 | 49.000 | 150 | N | 25.000 | 300.000 | 2.5 | 0.0061 | 20 | 10 | 39 | 16 |
|
|
DI0A4N45SQ2 | SMD | SO-8 | 450 | 0.400 | 150 | N | 2.000 | 1.600 | 4.0 | 4.5000 | 0 | 10 | 11 | 21 |
|
|
DI2A7N70D1K | SMD | TO-252AA/D-PAK | 700 | 2.700 | 150 | N | 34.400 | 6.000 | 3.5 | 1.6000 | 1 | 10 | 20 | 105 |
|
 |
DI4A7P06SQ2 | SMD | SO-8 | -60 | -4.700 | 150 | P | 3.000 | -30.000 | -2.3 | 0.0750 | -5 | -10 | 16 | 53 |
|
|
DI5A7N65D1K | SMD | TO-252AA/D-PAK | 650 | 5.700 | 150 | N | 36.000 | 25.000 | 4.0 | 0.4300 | 4 | 10 | 56 | 93 |
|
|
DI7A5N65D2K | SMD | TO-263AB/D2PAK | 650 | 7.500 | 150 | N | 62.500 | 25.000 | 4.0 | 0.4300 | 4 | 10 | 56 | 93 |
|
|
DI7A6N04SQ2 | SMD | SO-8 | 40 | 7.600 | 150 | N | 3.100 | 50.000 | 1.6 | 0.0280 | 7 | 10 | 50 | 44 |
|
|
DIT072N08-Q | Wire-lead | TO-220AB | 80 | 72.000 | 150 | N | 62.500 | 280.000 | 2.5 | 0.0090 | 20 | 10 | 29 | 74 |
|
|
DIW085N06-Q | Wire-lead | TO-247-3L | 65 | 85.000 | 150 | N | 240.000 | 340.000 | 4.0 | 0.0091 | 40 | 10 | 83 | 95 |
|
|
MD06P115-AQ | SMD | SOT-26 | -60 | -3.100 | 150 | P | 1.500 | -20.000 | -2.5 | 0.0850 | -4 | -10 | 20 | 17 |
|
|
MMBT7002K-Q | SMD | SOT-23 | 60 | 0.300 | 150 | N | 0.350 | 0.800 | 1.0 | 3.0000 | 1 | 10 | 20 | 20 |
|
|
MMBT7002KDW | SMD | SOT-363 | 60 | 0.300 | 150 | N+N | 0.350 | 1.200 | 2.1 | 3.0000 | 1 | 10 | 21 | 85 |
|
|
MMFTN138-AQ | SMD | SOT-23 | 50 | 0.220 | 150 | N | 0.360 | 0.880 | 0.8 | 3.5000 | 0 | 10 | 20 | 38 |
|
|
MMFTN3402-Q | SMD | SOT-23 | 30 | 4.000 | 150 | N | 1.000 | 15.000 | 1.0 | 0.0550 | 4 | 10 | 5 | 24 |
|
|
MMFTN3479KW | SMD | SOT-323 | 20 | 3.500 | 150 | N | 0.900 | 14.000 | 1.3 | 0.0640 | 2 | 5 | 5 | 21 |
|
|
MMFTN4520-Q | SMD | SOT-23 | 150 | 0.425 | 150 | N | 1.000 | 1.500 | 3.0 | 4.5000 | 0 | 5 | 64 | 86 |
|
|
MMFTN620KDW | SMD | SOT-363 | 60 | 0.350 | 150 | N+N | 0.410 | 0.500 | 1.0 | 2.0000 | 0 | 5 | 5 | 25 |
|
|
MMFTP3401-Q | SMD | SOT-23 | -30 | -4.000 | 150 | P | 1.400 | -27.000 | -1.3 | 0.0500 | -4 | -10 | 28 | 241 |
|
|
MMFTP5618-Q | SMD | SOT-23 | -60 | -1.250 | 150 | P | 0.500 | -10.000 | -3.0 | 0.1700 | -1 | -10 | 9 | 9 |
|
|
MMFTP6341KW | SMD | SOT-363 | -30 | -5.000 | 150 | P | 1.500 | -20.000 | 2.6 | 0.0590 | -3 | -10 | 20 | 17 |
|
|
MMFTP84K-AQ | SMD | SOT-23 | -60 | -0.180 | 150 | P | 0.250 | -0.700 | -1.4 | 10.0000 | 0 | -5 | 18 | 92 |
|
|
2N7002KPW-AQ | SMD | SOT-323 | 60 | 0.310 | 150 | N | 0.275 | 1.200 | 2.1 | 1.6000 | 1 | 10 | 8 | 20 |
|
|
DI018C03PT-Q | SMD | PowerQFN 3x3 | 30 | -18.000 | 150 | N+P | 10.800 | -80.000 | 2.5 | 0.0300 | -10 | -10 | 40 | 17 |
|
|
DI020N06D1-Q | SMD | TO-252AA/D-PAK | 60 | 20.000 | 150 | N | 25.000 | 50.000 | 2.5 | 0.0340 | 15 | 10 | 38 | 12 |
|
|
DI045N10PQ-Q | SMD | PowerQFN 5x6 | 100 | 45.000 | 150 | N | 40.000 | 400.000 | 2.5 | 0.0065 | 20 | 10 | 38 | 91 |
|
|
DI050N06D1-Q | SMD | TO-252AA/D-PAK | 60 | 50.000 | 150 | N | 42.000 | 160.000 | 1.8 | 0.0085 | 10 | 10 | 26 | 11 |
|
|
DI064P04D1-Q | SMD | TO-252AA/D-PAK | -40 | -64.000 | 150 | P | 48.300 | -350.000 | -4.0 | 0.0076 | -30 | -10 | 96 | 40 |
|
|
DI100N10PQ-Q | SMD | PowerQFN 5x6 | 100 | 80.000 | 150 | N | 50.000 | 480.000 | 2.4 | 0.0045 | 50 | 10 | 69 | 31 |
|
|
DI110N15PQ-Q | SMD | PowerQFN 5x6 | 150 | 110.000 | 150 | N | 62.000 | 145.000 | 2.5 | 0.0117 | 20 | 10 | 73 | 47 |
|
|
DI280N10TL-Q | SMD | HSOF-8/TOLL | 100 | 280.000 | 175 | N | 425.000 | 1200.000 | 4.2 | 0.0020 | 50 | 10 | 58 | 170 |
|
|
DI2A8N03PWK2 | SMD | PowerQFN 2x2 | 30 | 5.000 | 150 | N | 0.700 | 40.000 | 2.0 | 0.0200 | 10 | 10 | 27 | 20 |
|
|
DIT080N08-AQ | Wire-lead | TO-220AB | 80 | 80.000 | 150 | N | 62.500 | 480.000 | 1.2 | 0.0048 | 50 | 10 | 69 | 31 |
|
|
DIT085N10-AQ | Wire-lead | TO-220AB | 100 | 85.000 | 150 | N | 62.500 | 480.000 | 2.4 | 0.0048 | 50 | 10 | 69 | 31 |
|
|
MMBT7002K-AQ | SMD | SOT-23 | 60 | 0.300 | 150 | N | 0.350 | 0.800 | 1.0 | 3.0000 | 1 | 10 | 20 | 20 |
|
|
MMFTN138K-AQ | SMD | SOT-23 | 60 | 0.360 | 150 | N | 0.420 | 1.200 | 1.6 | 1.6000 | 0 | 10 | 27 | 12 |
|
|
MMFTN2362-AQ | SMD | SOT-23 | 60 | 3.000 | 150 | N | 1.250 | 12.000 | 2.5 | 0.0800 | 3 | 10 | 9 | 11 |
|
|
MMFTN490K-AQ | SMD | SOT-23 | 40 | 3.000 | 150 | N | 1.250 | 12.000 | 2.5 | 0.0720 | 3 | 10 | 15 | 7 |
|
|
MMFTN6190KDW | SMD | SOT-363 | 30 | 1.000 | 150 | N+N | 0.400 | 9.600 | 2.5 | 0.2800 | 1 | 10 | 14 | 45 |
|
|
MMFTP3160-AQ | SMD | SOT-23 | -30 | -2.600 | 150 | P | 1.400 | -20.000 | -2.0 | 0.0900 | -3 | -10 | 21 | 12 |
|
|
MMFTP3401-AQ | SMD | SOT-23 | -30 | -4.000 | 150 | P | 1.400 | -27.000 | -1.3 | 0.0500 | -4 | -10 | 28 | 241 |
|
|
MMFTP5618-AQ | SMD | SOT-23 | -60 | -1.250 | 150 | P | 0.500 | -10.000 | -3.0 | 0.1700 | -1 | -10 | 9 | 9 |
|
|
DI005N03PW-AQ | SMD | PowerQFN 2x2 | 30 | 5.000 | 150 | N | 0.700 | 40.000 | 2.0 | 0.0200 | 10 | 10 | 27 | 20 |
|
|
DI005P04PW-AQ | SMD | PowerQFN 2x2 | -40 | -5.400 | 150 | P | 2.000 | -40.000 | -2.5 | 0.0400 | -4 | -10 | 36 | 17 |
|
|
DI010N03PW-AQ | SMD | PowerQFN 2x2 | 30 | 10.000 | 150 | N | 1.400 | 50.000 | 2.0 | 0.0120 | 10 | 10 | 16 | 16 |
|
|
DI014N25D1-AQ | SMD | TO-252AA/D-PAK | 250 | 15.000 | 150 | N | 62.500 | 60.000 | 4.5 | 0.2800 | 15 | 10 | 9 | 12 |
|
|
DI017N06PQ-AQ | SMD | PowerQFN 5x6 | 60 | 17.000 | 150 | N | 21.000 | 50.000 | 2.5 | 0.0330 | 15 | 10 | 38 | 12 |
|
|
DI020N06D1-AQ | SMD | TO-252AA/D-PAK | 60 | 20.000 | 150 | N | 25.000 | 50.000 | 2.5 | 0.0340 | 15 | 10 | 38 | 12 |
|
|
DI020P06PT-AQ | SMD | PowerQFN 3x3 | -60 | -20.000 | 150 | P | 29.700 | -70.000 | -2.5 | 0.0450 | -10 | -10 | 29 | 29 |
|
|
DI025N06PT-AQ | SMD | PowerQFN 3x3 | 65 | 25.000 | 150 | N | 25.000 | 80.000 | 2.5 | 0.0200 | 8 | 10 | 13 | 7 |
|
|
DI035N10PT-AQ | SMD | PowerQFN 3x3 | 100 | 35.000 | 150 | N | 25.000 | 130.000 | 1.7 | 0.0140 | 7 | 10 | 21 | 17 |
|
|
DI035P04PT-AQ | SMD | PowerQFN 3x3 | -40 | -35.000 | 150 | P | 25.000 | -120.000 | -1.7 | 0.0190 | -10 | -10 | 40 | 32 |
|
|
DI040N03PT-AQ | SMD | PowerQFN 3x3 | 30 | 40.000 | 150 | N | 25.000 | 120.000 | 1.7 | 0.0060 | 15 | 10 | 84 | 34 |
|
|
DI040P04D1-AQ | SMD | TO-252AA/D-PAK | -40 | -40.000 | 150 | P | 52.000 | -160.000 | -2.5 | 0.0150 | -10 | -10 | 44 | 30 |
|
|
DI040P04PT-AQ | SMD | PowerQFN 3x3 | -40 | -40.000 | 150 | P | 22.700 | -160.000 | -1.7 | 0.0150 | -10 | -10 | 19 | 26 |
|
|
DI045N03PT-AQ | SMD | PowerQFN 3x3 | 30 | 45.000 | 150 | N | 16.000 | 280.000 | 1.7 | 0.0034 | 24 | 10 | 72 | 26 |
|
|
DI045N10PQ-AQ | SMD | PowerQFN 5x6 | 100 | 45.000 | 150 | N | 40.000 | 400.000 | 2.5 | 0.0065 | 20 | 10 | 38 | 23 |
|
|
DI048N04PQ-AQ | SMD | PowerQFN 5x6 | 40 | 48.000 | 150 | N | 28.000 | 200.000 | 1.8 | 0.0080 | 12 | 10 | 47 | 19 |
|
|
DI048N04PT-AQ | SMD | PowerQFN 3x3 | 40 | 48.000 | 150 | N | 31.000 | 200.000 | 2.5 | 0.0076 | 10 | 10 | 47 | 19 |
|
|
DI050N04PT-AQ | SMD | PowerQFN 3x3 | 40 | 50.000 | 150 | N | 25.000 | 220.000 | 2.5 | 0.0057 | 10 | 10 | 48 | 24 |
|
|
DI050N06D1-AQ | SMD | TO-252AA/D-PAK | 60 | 50.000 | 150 | N | 42.000 | 160.000 | 1.8 | 0.0085 | 10 | 10 | 26 | 11 |
|
|
DI050P03PT-AQ | SMD | PowerQFN 3x3 | -30 | -50.000 | 150 | P | 39.000 | -200.000 | -2.5 | 0.0080 | -20 | -10 | 75 | 34 |
|
|
DI064P04D1-AQ | SMD | TO-252AA/D-PAK | -40 | -64.000 | 150 | P | 48.300 | -350.000 | -4.0 | 0.0076 | -30 | -10 | 96 | 40 |
|
|
DI068N03PQ-AQ | SMD | PowerQFN 5x6 | 30 | 68.000 | 150 | N | 25.000 | 210.000 | 1.6 | 0.0030 | 20 | 10 | 60 | 30 |
|
|
DI068P04D1-AQ | SMD | TO-252AA/D-PAK | -40 | -68.000 | 150 | P | 54.000 | -300.000 | -2.5 | 0.0073 | -20 | -10 | 85 | 52 |
|
|
DI070P04PQ-AQ | SMD | PowerQFN 5x6 | -40 | -70.000 | 150 | P | 46.000 | -300.000 | -2.5 | 0.0065 | -30 | -10 | 37 | 43 |
|
|
DI075N04PT-AQ | SMD | PowerQFN 3x3 | 40 | 75.000 | 150 | N | 35.700 | 400.000 | 2.5 | 0.0028 | 23 | 10 | 60 | 25 |
|
|
DI080N06PQ-AQ | SMD | PowerQFN 5x6 | 65 | 105.000 | 150 | N | 80.000 | 480.000 | 2.0 | 0.0030 | 40 | 10 | 31 | 138 |
|
|
DI087N03D1-AQ | SMD | TO-252AA/D-PAK | 30 | 87.000 | 150 | N | 41.670 | 420.000 | 2.5 | 0.0030 | 20 | 10 | 70 | 23 |
|
|
DI100N04D1-AQ | SMD | TO-252AA/D-PAK | 40 | 100.000 | 150 | N | 69.000 | 450.000 | 2.5 | 0.0040 | 30 | 10 | 103 | 46 |
|
|
DI100N04PQ-AQ | SMD | PowerQFN 5x6 | 40 | 100.000 | 150 | N | 83.000 | 400.000 | 2.4 | 0.0021 | 50 | 10 | 16 | 45 |
|
|
DI100N10PQ-AQ | SMD | PowerQFN 5x6 | 100 | 80.000 | 150 | N | 50.000 | 480.000 | 2.4 | 0.0045 | 50 | 10 | 69 | 31 |
|
|
DI105N04PQ-AQ | SMD | PowerQFN 5x6 | 40 | 105.000 | 150 | N | 83.000 | 520.000 | 2.4 | 0.0026 | 50 | 10 | 20 | 38 |
|
|
DI110N03PQ-AQ | SMD | PowerQFN 5x6 | 30 | 110.000 | 150 | N | 35.000 | 420.000 | 2.5 | 0.0018 | 30 | 10 | 114 | 54 |
|
|
DI110N04PQ-AQ | SMD | PowerQFN 5x6 | 40 | 110.000 | 150 | N | 45.000 | 450.000 | 1.7 | 0.0025 | 23 | 10 | 61 | 24 |
|
|
DI110N06D1-AQ | SMD | TO-252AA/D-PAK | 65 | 110.000 | 150 | N | 71.000 | 550.000 | 2.5 | 0.0032 | 30 | 10 | 65 | 31 |
|
|
DI110N15PQ-AQ | SMD | PowerQFN 5x6 | 150 | 110.000 | 150 | N | 62.000 | 145.000 | 2.5 | 0.0117 | 20 | 10 | 73 | 47 |
|
|
MMBT7002CK-AQ | SMD | SOT-23 | 60 | 0.300 | 150 | N | 0.350 | 2.000 | 2.5 | 2.0000 | 1 | 10 | 8 | 20 |
|
|
MMBT7002KW-AQ | SMD | SOT-323 | 60 | 0.300 | 150 | N | 0.250 | 1.400 | 1.7 | 1.6000 | 1 | 10 | 21 | 85 |
|
|
MMFTN3404A-AQ | SMD | SOT-23 | 30 | 5.600 | 150 | N | 1.250 | 22.000 | 2.1 | 0.0230 | 6 | 10 | 40 | 14 |
|
|
MMFTN3422K-AQ | SMD | SOT-23 | 30 | 4.200 | 150 | N | 1.250 | 20.000 | 1.2 | 0.0420 | 4 | 10 | 1206 | 991 |
|
|
MMFTN620KD-AQ | SMD | SOT-26 | 60 | 0.350 | 150 | N | 0.500 | 1.000 | 1.5 | 1.5000 | 1 | 10 | 8 | 31 |
|
|
MMFTP2319A-AQ | SMD | SOT-23 | -40 | -4.200 | 150 | P | 0.750 | -30.000 | -2.5 | 0.0970 | -3 | -10 | 8 | 10 |
|
|
MMFTP3008K-AQ | SMD | SOT-23 | -30 | -0.360 | 150 | P | 0.500 | -1.400 | -1.0 | 2.5000 | 0 | -5 | 16 | 60 |
|
|
MMFTP3334K-AQ | SMD | SOT-23 | -30 | -4.000 | 150 | P | 1.000 | -16.000 | -1.4 | 0.0710 | -3 | -10 | 13 | 22 |
|
|
DI001N65PTK-AQ | SMD | PowerQFN 3x3 | 650 | 1.000 | 150 | N | 32.200 | 4.000 | 2.5 | 1.6000 | 1 | 10 | 20 | 105 |
|
|
DI028N10PQ2-AQ | SMD | PowerQFN 5x6-Dual | 100 | 28.000 | 150 | N+N | 28.000 | 130.000 | 2.5 | 0.0210 | 7 | 10 | 16 | 15 |
|
|
DI038N04PQ2-AQ | SMD | PowerQFN 5x6-Dual | 45 | 38.000 | 150 | N+N | 31.000 | 160.000 | 1.6 | 0.0100 | 10 | 10 | 47 | 19 |
|
|
DI048N04PQ2-AQ | SMD | PowerQFN 5x6-Dual | 40 | 48.000 | 150 | N+N | 28.000 | 200.000 | 1.8 | 0.0080 | 12 | 10 | 47 | 19 |
|
|
DI049N06PTK-AQ | SMD | PowerQFN 3x3 | 65 | 49.000 | 150 | N | 25.000 | 300.000 | 2.5 | 0.0061 | 20 | 10 | 39 | 16 |
|
|
DI052N04PQ2-AQ | SMD | PowerQFN 5x6-Dual | 40 | 52.000 | 150 | N+N | 25.000 | 240.000 | 2.5 | 0.0047 | 10 | 10 | 61 | 24 |
|
|
DI5A7N65D1K-AQ | SMD | TO-252AA/D-PAK | 650 | 5.700 | 150 | N | 36.000 | 25.000 | 4.0 | 0.4300 | 4 | 10 | 56 | 93 |
|
|
DI7A5N65D2K-AQ | SMD | TO-263AB/D2PAK | 650 | 7.500 | 150 | N | 62.500 | 25.000 | 4.0 | 0.4300 | 4 | 10 | 56 | 93 |
|
|
MMBT7002KDW-AQ | SMD | SOT-363 | 60 | 0.300 | 150 | N+N | 0.350 | 1.200 | 2.1 | 3.0000 | 1 | 10 | 21 | 85 |
|
|
MMFTN620KDW-AQ | SMD | SOT-363 | 60 | 0.350 | 150 | N+N | 0.200 | 0.500 | 1.0 | 2.0000 | 0 | 5 | 5 | 25 |
 |
|
DI0A35N06PGK-AQ | SMD | DFN1006-3 | 60 | 0.350 | 150 | N | 0.223 | 1.200 | 1.0 | 1.4000 | 1 | 10 | 7 | 31 |
|
|
DI2A8N03PWK2-AQ | SMD | PowerQFN 2x2 | 30 | 5.000 | 150 | N | 0.700 | 40.000 | 2.0 | 0.0200 | 10 | 10 | 27 | 20 |
*Please refer to the specification sheet for more details.
Horustech is a Diotec distributor that provides various semiconductor components. If you have any related needs, please feel free to contact us online.
Back
